| ELECTRICAL Characteristics (STC) | |||||
|---|---|---|---|---|---|
| Maximum Power - Pmax (W) | 100 | 110 | 120 | 130 | 140 |
| Open Circuit Voltage - Voc (V) | 20.60 | 21.23 | 21.60 | 21.95 | 23.16 |
| Short Circuit Current - Isc (A) | 5.94 | 6.41 | 6.87 | 7.21 | 7.46 |
| Maximum Power Voltage - Vmpp (V) | 17.82 | 18.15 | 18.48 | 19.08 | 19.80 |
| Maximum Power Current - Impp (A) | 5.62 | 6.07 | 6.50 | 6.82 | 7.08 |
| Module Efficiency (%) | 18.80 | 20.70 | 22.69 | 21.30 | 20.30 |
| Temperature Characteristics | |||||
| Pmax Temperature Coefficient | -0.40% / ℃ | ||||
| Voc Temperature Coefficient | -0.32% / ℃ | ||||
| Isc Temperature Coefficient | +0.05% / ℃ | ||||
| Operating Temperature | -40 to +85 ℃ | ||||
| Nominal Operating Cell Temperature (NOCT) | 45±2 ℃ | ||||
| ELECTRICAL Characteristics (STC) | |||||
|---|---|---|---|---|---|
| Maximum Power - Pmax (W) | 150 | 160 | 170 | 180 | 190 |
| Open Circuit Voltage - Voc (V) | 23.58 | 21.05 | 21.53 | 24.42 | 24.88 |
| Short Circuit Current - Isc (A) | 7.86 | 9.31 | 9.71 | 9.02 | 9.35 |
| Maximum Power Voltage - Vmpp (V) | 20.16 | 18.15 | 18.48 | 21.06 | 21.45 |
| Maximum Power Current - Impp (A) | 7.45 | 8.82 | 9.20 | 8.55 | 8.86 |
| Module Efficiency (%) | 21.70 | 19.50 | 20.70 | 17.80 | 18.80 |
| Temperature Characteristics | |||||
| Pmax Temperature Coefficient | -0.40% / ℃ | ||||
| Voc Temperature Coefficient | -0.32% / ℃ | ||||
| Isc Temperature Coefficient | +0.05% / ℃ | ||||
| Operating Temperature | -40 to +85 ℃ | ||||
| Nominal Operating Cell Temperature (NOCT) | 45±2 ℃ | ||||
